Chassis

CSE-505-203B



Key Features

1. 5x 3.5" Hot-swap SATA Hard Disk

    Drive Trays
2. Fan Failure LED and Alarm
3. Overheat LED
4. Drive Activity LED
5. Drive Failure LED
6. 3x 5.25" Drive Bay Enclosure
7. 9cm Cooling Fan Subsystem


Available Colors
  Black
Downloads
Manual
Specifications
Dimensions
Height 5" (127mm)
Width 5.8" (147mm)
Depth 9.7" (245mm): with fan

7.7" (195mm): without fan
Gross Weight 7.5 lbs (3.4kg): with package

6 lbs (2.6kg): mobile rack only
Available Colors Black
Occupancy
• 3x 5.25" Drive Bays
Capacity
5x 3.5" Hot-swap SAS/SATA HDDs with SES2
Cooling Sub-system
Fans 1x 90mm Exhaust Fan
System Monitoring
LEDs / Alarms • Fan Fail LED and Alarm

• Overheat LED Indication Alarm

• Drive Activity Indication and Alarm
Compatibility
Chassis • SC748 Series

• SC747 Series

• SC745 Series

• SC743 Series


Parts List
